Ubiquiti UniFi Dream Wall. Wall-mountable UniFi Cloud Gateway. Built-in WiFi 6 Access Point. PoE Switching. UniFi OS Console. 3.5+ Gbps
Wall-mounted 10G Cloud Gateway with integrated WiFi 6. high-power PoE switching. and full UniFi application support.
- Built-in WiFi 6 AP
- Includes full UniFi application suite for device management
- 3.5+ Gbps routing with IDS/IPS
- (1) 10G SFP+*. (17) GbE RJ45 LAN ports including (4) PoE++. (4) PoE+. and (4) PoE ports
- (1) 10G SFP+*. (1) 2.5 GbE RJ45 WAN ports
- 4.7' touchscreen for management
- Integrated 128 GB SSD & pre-installed 512 GB microSD card
*Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.
MECHANICAL
Dimensions: 549 x 342 x 62 mm (21.6 x 13.5 x 2.4')
Weight: 8.6 kg (19 lb)
Enclosure material: Polycarbonate. galvanized steel. aluminum alloy
Mount material: Stainless steel
HARDWARE
Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
System memory: 4 GB DDR4
On-board storage:
16 GB eMMC
Integrated 128 GB SSD
Pre-installed 512 GB microSD card
Expansion slot Micro SD memory card*
*Requires a memory card with at least 128 GB of storage.
Management interface: Ethernet . Bluetooth . WiFi
Networking interface
LAN: (17) GbE RJ45 ports ; (1) 10G SFP+ port
WAN: (1) 2.5 GbE RJ45 port ; (1) 10G SFP+ port
PoE interface
(4) PoE (Pair A 1. 2+; 3. 6-)
(4) PoE+ (Pair A 1. 2+; 3. 6-)
(4) PoE++ (Pair A 1. 2+; 3. 6-) (Pair B 4. 5+; 7. 8-)
Power method: Universal AC input 100—240V AC. 7A Max.. 50/60Hz
Power supply: (2) Hot-Swappable AC/DC 550W PSU**Comes with (1) pre-installed PSU.
Max. power consumption: 532W (Including PoE output)
PoE budget: 420W
ESD/EMP protection: Air: ± 8kV. contact: ± 4kV
LCM display: (1) 4.7' touchscreen
Button: Factory reset
Mounting: Wall mount (included)
Ambient operating temperature: -10 to 40° C (14 to 104° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: CE. FCC. IC
SOFTWARE
WiFi standards: 802.11a/b/g/n/ac/ax
Wireless security: WEP. WPA-PSK. WPA-Enterprise (WPA/WPA2/WPA3)
BSSID: 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest traffic isolation : Supported
Concurrent clients: 300+
LEDs
Ethernet: White: link/activity
SFP+: White: link/activity
PSU: Blue: ready ; Amber: failure
